Write a reviewIn-Tank 8mm PTFE hose SAE 5/16" 90° fitting
This PTFE hose is mounted in the fuel tank or catch tank between the fuel pump hose connection and a SAE 3/8" quick connection.
This solution increases safety, simplifies assembly and service and can handle all types of fuel. One end has a Hurricane SAE quick coupler fitted, and the other end is open to fit to the fuel pump.
Safety
An additional o-ring is fitted, improving safety beyond the SAE J2044 standard.
Installation
The hose is extremely flexible and simplifies the fuel pump installation in a fuel tank or catch tank.
Usage
This solution can handle all types of fuel, racing fuel, ethanol, and methanol, as the hose is made of PTFE.
Service
All types of maintenance and service are greatly simplified as the quick coupling is pushed in so the latches can be released. This is easily done with just one hand.
Specification:
ID: 10mm
Material: PTFE
Length: 45cm
Max working pressure SAE J2044: 5bar / 72psi (Use supplied hose clamp and increase working pressure to max 10bar)
Max working temperature: -40°C - +110°C
Matching fuel pumps and SAE quick fitting adapters are linked below:
----------------
